Materials & Technology

FR-4, High TG, Rogers, Teflon, Taconic, CEM-1, CEM-3, Blind & Buried Via’s, Micro Via’s, Impedance Control, Halogen Free, Carbon Ink, Peel able Solder Mask, Kapton Tape, Conductive Ink & Copper Filled Via’s.

PDF Download of our PCB Capabilities

Surface Finish / Leaded – HASL (Hot Air Solder Levelled).

Surface Finish – Lead Free ROHS – Immersion Gold, Immersion Silver, Immersion Tin, OSP Flux, Lead Free HAL.

All PCB’s are manufactured with UL & ISO9001:2000 accredited manufacturers as well as TS16949 approval for the Automotive industry.

PDF Download of a Standard PCB Layer Stack Up

FR-4 Data Specifications:

S1141 - UV Blocking
S1170 - Excellent Thermal Resistance / High Tg

Rogers Corp. Material Data Specifications:

RO4000 - High Frequency Circuit Boards
RO4350B - High Frequency Circuit Boards

ARLON Material Data Specifications:

85N - Polyimide Laminate and Prepreg

Express PCB Prototype Service via DHL

2 Layer – 24 hours + DHL
4 Layer – 48 hours + DHL
6 Layer – 3 working days + DHL
8 Layer – 4 working days + DHL
10 Layer – 5 working days + DHL

Standard PCB Prototype Service via DHL

2 Layer – 5 working days + DHL
4 Layer – 6 working days + DHL
6 Layer – 7 working days + DHL
8 Layer – 8 working days + DHL
10 Layer – 10 working days + DHL
